LC1-D8011 3-Pole AC Contactor for Three-Phase Motor Control

Product Features

The Bentong LC1-D8011 is a 3-pole AC contactor designed for switching and controlling three-phase AC loads. The product features clearly marked L1, L2 and L3 input terminals and T1, T2 and T3 output terminals, making connection and circuit identification convenient.

The front of the contactor is clearly marked with the LC1-D8011 model and electrical ratings. The integrated auxiliary contact section is marked 21NC and 13NO, supporting control and signal functions in electrical control circuits.

Application

The LC1-D8011 is suitable for three-phase motor control and AC load switching applications. Typical applications include electrical control panels, industrial automation equipment, motors, pumps, fans, compressors and other electrical equipment requiring contactor-based switching and control.

Specifications

Model: LC1-D8011

Product type: AC Contactor

Number of poles: 3 poles

Rated thermal current Ith: 125A

Rated insulation voltage Ui: 690V

Main terminals: L1 / L2 / L3 and T1 / T2 / T3

Auxiliary contacts: 13NO / 21NC

AC-3 rating shown on product: 660/690V, 45kW

Three-phase motor power shown on product: 220/230V, 22kW; 380/400V, 37kW

Product Details

The contactor adopts a compact molded structure with a clearly organized terminal layout. The main terminals and auxiliary contact markings are directly visible on the product, helping users identify connection points during installation. The product nameplate also shows IEC 60947, GB 14048.4 and VDE 0660 markings, together with CE marking.
